Victron Argofet 100-2 Battery Isolator (FET), 2 batteries / 100A, ARG100201020 (R)
€107.00
Argofet battery isolators allow simultaneous charging of two or more batteries from a single alternator or a single-output charger, without connecting the batteries together. Compared to Argodiode isolators, Argofet models feature virtually no voltage loss, ensuring more efficient charging and minimal energy drop.
Victron Argofet 100-2 Battery Isolator (FET), 2 batteries / 100A, ARG100201020 (R)
The Victron Argofet 100-2 is a high-efficiency FET battery isolator designed for safely charging two independent battery banks from one alternator or charger. FET technology ensures an ultra-low voltage drop (<0.02 V at low current and around 0.1 V at higher current), providing optimal charging efficiency.
Voltage drop examples:
• 100 A through 50 mm² cable (10 m) → ≈0.26 V
• 50 A through 10 mm² cable (5 m) → ≈0.35 V
Alternator energize input:
Some alternators require DC voltage at the B+ terminal to start charging. The Argofet models include a current-limited energize input that ensures proper alternator operation.
Key advantages
- Simultaneous charging of 2 independent battery banks
- FET technology – extremely low voltage loss
- More efficient than diode-based isolators
- Prevents reverse current between batteries
- Ideal for marine, RV, solar and industrial power systems
- Durable and long-lasting construction
Technical Specifications
| Model | Victron Argofet 100-2 |
| Product code | ARG100201020 (R) |
| Maximum current | 100 A |
| Max alternator current | 100 A |
| Number of batteries | 2 |
| Nominal voltage | 12 V / 24 V |
| Connections | M8 bolts |
| Voltage drop | <0.02 V / ~0.1 V |
| Dimensions | 65 × 120 × 200 mm |
| Weight | 0.65 kg |
