Lofrans Windlass V. ERC. S/S G+D HYD/ 16mm Lofrans Ercole Verticale
Previous
Next
Lofrans Windlass V. ERC. S/S G+D HYD/ 16mm Lofrans Ercole Verticale

Lofrans Windlass V. ERC. S/S G+D HYD/ 16mm

SKU 602525 Category Lofrans Ercole Verticale
€14,321.95

The Lofrans ERCOLE hydraulic vertical windlass is designed for large yachts and professional vessels requiring exceptional power, reliability and continuous-duty operation. Mirror-polished AISI 316 stainless steel construction and a robust hydraulic drive ensure safe and controlled anchoring in the most demanding marine environments.

Motor size
Type
Gypsy
Add to Cart

The Lofrans ERCOLE hydraulic vertical windlass is engineered for professional and heavy-duty marine applications. Compact under-deck dimensions allow efficient installation, while mirror-polished AISI 316 stainless steel construction ensures superior corrosion resistance. Independent gypsy and drum operation enables precise chain handling, and manual chain release with manual override provides operational safety in all conditions.

Main Features

  • Compact under-deck dimensions
  • Mirror-polished AISI 316 stainless steel construction
  • Hydraulic drive for continuous-duty operation
  • Drum brake for chain control
  • High-grip gypsy with independent rotation
  • Independent gypsy and drum operation
  • Manual chain release
  • Manual override

Technical Specifications

Product Code 602525 602526
Rotation CW CCW
Chain Size 16 mm (ISO 4565)
Hydraulic Flow 40 l/min
Hydraulic Pressure 200 bar
Line Speed at W.L. 12 m/min
Maximum Line Speed 12 m/min
Maximum Pull 6500 kg
Drive Type Hydraulic – 11 cc
Net Weight 165 kg
Configuration With Drum (G+D)

Standard Equipment

  • Gypsy for chain
  • Handle
  • Instruction manual
