X1 - Vertical Windlass, 12V, Dark 8mm - ISO 4565/DIN 766, 800W, With Drum X1 & SX1 Vertical windlasses 500–800 W

X1 - Vertical Windlass, 12V, Dark 8mm - ISO 4565/DIN 766, 800W, With Drum

SKU 636702 Category X1 & SX1 Vertical windlasses 500–800 W
€1,048.00

The Lofrans X1 Dark vertical windlass with drum is designed for safe and efficient anchoring on sailing and motor boats from 6 to 27 meters. The Dark version features a modern dark finish combined with the proven reliability of the X1 series. An 800 W motor operating on a 12 V system delivers stable hauling speed and strong pulling force for combined chain and rope operation in demanding marine conditions.

Add to Cart

Lofrans X1 Dark vertical windlass with drum combines the proven mechanics of the X1 series with a modern dark finish. The vertical configuration allows a clean below-deck installation and efficient use of space.

Designed for combined chain and rope operation, the windlass provides stable line speed and strong pulling performance. Robust construction and a powerful electric motor ensure reliable and long-lasting operation in harsh marine environments.

Technical specifications

Product code 636702
Model X1 DARK G+D 800W / 12V
Chain 8 mm ISO 4565 / DIN 766
Rope 12 mm, 3-strand
Line speed at working load 25 m/min
Maximum speed 28 m/min
Maximum pull 700 kg
Motor power 800 W
Voltage 12 V
Type With drum
Weight 14 kg
Working load 100 kg

Documentation:
User manual
Product brochure
