MAX POWER CT25 – set tunnel thruster, 12V – 1.8(kW)/2.4(hp) – 30kgf – D110mm – Mono MAX POWER Electric Tunnel Thruster – Comp...

MAX POWER CT25 – set tunnel thruster, 12V – 1.8(kW)/2.4(hp) – 30kgf – D110mm – Mono

SKU SET636061 Category MAX POWER Electric Tunnel Thruster – Complete Kits
€1,147.74

The MAX POWER CT25 12V tunnel thruster installation set is an ideal solution for precise and safe lateral maneuvering of smaller motorboats and sailing yachts. The set includes a CT25 mono electric tunnel thruster, a Ø110 mm fiberglass tunnel (750 mm), a touch control panel, an ANL 150A fuse with holder, and tinned marine cable. Designed for vessels up to approximately 7.3 m in length, it provides reliable assistance during docking and maneuvering in confined spaces.

Add to Cart

The MAX POWER CT25 12V tunnel thruster installation set is a complete solution for improving bow or stern maneuverability on smaller motorboats and sailing yachts. It is designed for vessels up to approximately 7.3 m in length, where a compact, reliable, and easy-to-use maneuvering aid is required.

At the heart of the set is the Max Power CT25 Electric Tunnel Thruster with a mono propeller, offering an optimal balance between power, compact size, and energy efficiency. As the smallest model in the Max Power electric tunnel thruster range, the CT25 maintains high build quality and long-term reliability.

Thanks to its composite drive leg, advanced DC motor, and maintenance-free design (no anodes), the CT25 is a cost-effective and durable choice for smaller vessels.

In its 12V configuration, the CT25 delivers up to 30 kgf of thrust with a power output of 1.8 kW (2.4 hp). This level of thrust is sufficient for effective lateral movement of light to mid-weight boats within its class.

The set includes a Ø110 mm fiberglass tunnel with a length of 750 mm, ensuring optimal water flow and rated performance. The fiberglass construction provides a strong, corrosion-resistant, and easy-to-install solution.

Electrical protection is ensured by an ANL fuse holder and an ANL 150A fuse, matched to the CT25’s power requirements. A 12.5 m tinned marine cable is included to support a reliable marine-grade electrical installation.

Control is provided via the Max Power Touch Control Panel (black), offering intuitive and precise operation. The touch panel supports short thrust pulses and fine control, with integrated safety features such as overheat protection and automatic shutdown.

Set Contents

  • MAX POWER CT25 Electric Tunnel Thruster, Mono propeller, 12V
  • MAX POWER Touch Control Panel, black
  • MAX POWER Fiberglass Tunnel Ø110 × L750
  • MAX POWER ANL Fuse Holder
  • MAX POWER ANL Fuse 150A (12V system)
  • Tinned marine cable, black, 12.5 m

Technical Specifications – CT25 (12V)

Model Max Power CT25 Electric Tunnel Thruster
Voltage 12 V
Maximum thrust up to 30 kgf
Power output 1.8 kW / 2.4 hp
Propeller Mono (single propeller)
Drive leg material Composite
Tunnel diameter Ø110 mm
Tunnel (included) Fiberglass Ø110 × L750
Thruster weight approx. 7 kg
Fuse (included) ANL 150A + holder
Cable (included) Tinned marine cable, 12.5 m
