WDL H. S. ERC. W.ALU T.B G+D HYD/ 16mm Horizontal Windlasses

WDL H. S. ERC. W.ALU T.B G+D HYD/ 16mm

SKU 602491 Category Horizontal Windlasses

€18,225.00

LOFRANS SUPER ERCOLE Hydraulic Horizontal Windlass is a heavy-duty hydraulic anchoring solution designed for professional and commercial vessels equipped with onboard hydraulic systems. This Type B version features a marine-grade white aluminium body and supports a 16 mm anchor chain, ensuring maximum reliability and performance in continuous-duty applications.

The LOFRANS SUPER ERCOLE Hydraulic Horizontal Windlass – Model 602491 is engineered for intensive anchoring operations on professional and commercial vessels requiring continuous-duty performance. Manufactured with a marine-grade white aluminium construction, it provides excellent corrosion resistance, structural strength, and long-term durability in harsh marine environments.

This configuration represents the Type B hydraulic version, designed to operate exclusively with an onboard hydraulic system. The windlass supports independent gypsy and drum operation, manual chain release, and manual override, ensuring safe, precise, and controlled anchoring under heavy loads.

Main Features

Marine-grade white aluminium construction
Hydraulic drive for continuous professional use
Independent gypsy and drum operation
Manual chain release
Manual override
Suitable for vessels with onboard hydraulic systems

Technical Specifications

Model	602491
Windlass Type	Horizontal
Version	Type B – Hydraulic
Chain Size	16 mm
Drive Type	Hydraulic
Required Hydraulic Flow	40 l/min
Working Pressure	200 bar
Maximum Pull	6500 kg
Line Speed	18 m/min
Operation	Gypsy & Drum
Net Weight	215 kg
Other versions available on request
